| Electrical Specifications |
| Connector Impedance |
50 ohm |
| Operating Frequency Band |
0 – 2700 MHz |
| Cable Impedance |
50 ohm |
| 3rd Order IMD, typical |
-116 dBm @ 1800 MHz |
| 3rd Order IMD Test Method |
Two +43 dBm carriers |
| RF Operating Voltage, maximum (vrms) |
707.00 V |
| dc Test Voltage |
2000 V |
| Outer Contact Resistance, maximum |
0.30 mOhm |
| Inner Contact Resistance, maximum |
2.00 mOhm |
| Insulation Resistance, minimum |
5000 MOhm |
| Average Power |
0.6 kW @ 900 MHz |
| Peak Power, maximum |
10.00 kW |
| Insertion Loss, typical |
0.05 dB |
| Shielding Effectiveness |
-130 dB |
