Description
Design Features
- Switch mode technology for high efficiency, lightweight and quiet operation
- Automatic operation for ALL Lead Acid Batteries Flooded, AGM or Gel Cell
- Can charge 2 banks of batteries simultaneously, no isolator necessary
- Can be used as a power supply or DC UPS when used in conjunction with a battery
- User Configurable AC Input voltage 120 or 230 VAC, 50 / 60 Hz
- User Selectable ( by DIP Switch) for 2 or 3 stage, rapid and safe charging of standalone and loaded Lead Acid Batteries
- “Half Power Mode” reduces maximum charging current to half the rated capacity, allows for safe charging of lower capacity batteries
- Voltmeter and Ammeter for monitoring
- Fan cooled based on output current
- Protections: Short circuit, overload, reverse battery connection and over temperature
- Includes temperature sensor to prevent under/overcharging of battery if temperature varies extensive
Specifications
- Input:120 VAC 60 Hz or 230 VAC 50 Hz
- Output:12 VDC
- Amps: 80
- Remote Control: 900-RC
- Weight: 9 lbs (4.1 kg)
- Dimensions: 15 x 9.61 x 3.82” (381 x 244 x 97 mm)
- Safety: Intertek ETL Listed to meet UL Standard UL-1564, EMI Compliant to FCC Part 15(B), Class B
Applications
- Automotive
- Recreational vehicles
- Marine
- Communications sites
- Battery back-up systems
